Ultrasonic high frequency screen

Ultrasonic high-frequency screen, also known as ultrasonic high-frequency vibrating screen, is designed and produced to solve the screening problems such as screen blocking, screen sticking, adsorption, troupe, static electricity, light specific gravity and so on.

The high-frequency vibrating screen (high-frequency screen) is composed of vibration exciter, screen frame, frame, suspension spring, screen mesh and other components.

The high-frequency vibrating screen adopts cylindrical eccentric shaft exciter and eccentric block to adjust the amplitude. The material screen has long flow line and many screening specifications. It has the characteristics of stable structure, strong exciting force, high screening efficiency, low vibration noise, durability, convenient maintenance and safe use. The high-frequency vibrating screen can be applied to the product classification of food, medicine, chemical industry, new energy and other industries.

Working Principle

Because the high frequency vibrating screen (high frequency screen) adopts high

frequency, on the one hand, it destroys the tension of the material surface and the

high-speed oscillation of fine materials on the screen surface, accelerates the

separation of high-density materials and increases the probability of contact between

materials smaller than the separation particle size and the screen hole. This results in

better separation conditions, so that the materials smaller than the separation particle

size, especially the particles with large specific gravity, can pass through the sieve hole

together with the slurry and become the products under the sieve.

Product Features

The ultrasonic frequency vibrating screen has high screening accuracy and efficiency,and can be used for any powder, particle and slurry;

3. The screen hole of ultrasonic frequency vibration screen is not blocked, the powder

is not flying, and the vibration frequency is high, up to 3000 times / min, which has

obvious screening effect on fine-grained and high viscosity materials; The equipment

can effectively handle solid-liquid mixed materials and quickly realize solid-liquid

separation, which is 2-5 times higher than that of ordinary high-frequency screen.

3. The ultrasonic high-frequency vibrating screen has a unique screen structure, which

is convenient and fast to install. It only takes 3 ~ 5 minutes. It has the advantages of

simple operation, convenient cleaning, no dead corner and no residue;

4. The ultrasonic high-frequency vibrating screen has no mechanical action and simple

maintenance. Except for the motor, the rest are made of all stainless steel;

5. The ultrasonic high-frequency vibrating screen can be installed with movable frame,

which can be moved freely in the workplace, and the height can be adjusted. It does

not need complex installation, and the operation is simple and not easy to be damaged.

Equipment parameters
