Standard pharmacopoeia sieve

Pharmacopoeia sieve overview

China pharmacopoeia stipulate No.1-9 is pharmacopoeia standard sieve, No.1 is the biggest mesh, meshes are 10 mesh, 24 mesh, 50 mesh, 65 mesh, 80 mesh, 100 mesh, 120 mesh, 150 mesh and 200 mesh. It is used for liquid, powder, solid particles screening in pharmaceutical companies. It is used for screening liquid, powder, solid particles in pharmaceutical companies. Pharmacopoeia sieve can be screening by hands. In order to improve the efficiency, it also can be used with the test sieve machine or slap vibrating sieve machine together.

Pharmacopoeia sieve model

Sieve diameter and height are standard 200 mm*50 mm

Name	Sieve number	Mesh	Mesh size(μm）	The mesh tolerance
Pharmacopoeia sieve	S-1	10	2000	±70μm
Pharmacopoeia sieve	S-2	24	850	±29μm
Pharmacopoeia sieve	S-3	50	355	±13μm
Pharmacopoeia sieve	S-4	65	250	±9.9μm
Pharmacopoeia sieve	S-5	80	180	±7.6μm
Pharmacopoeia sieve	S-6	100	150	±6.6μm
Pharmacopoeia sieve	S-7	120	125	±5.8μm
Pharmacopoeia sieve	S-8	150	90	±4.6μm
Pharmacopoeia sieve	S-9	200	75	±4.1μm

Standard pharmacopoeia sieve features

1. Strong and durable
2. Double package edge design, there is no steel cross section, no burr, it won’t scratch hand, complying with the requirement of safe operation.
3. Sieve box adopts SUS304 stainless steel material, conform to the requirements of the health, food and pharmaceutical industry.
4. Screen is made of stainless steel woven, aperture conform to GB6003.1-2012 standard. After strict inspection, product will be shipped form factory.

Standard pharmacopoeia sieve features
1. Strong and durable
2. Double package edge design, there is no steel cross section, no burr, it won’t scratch hand, complying with the requirement of safe operation.
3. Sieve box adopts SUS304 stainless steel material, conform to the requirements of the health, food and pharmaceutical industry.
4. Screen is made of stainless steel woven, aperture conform to GB6003.1-2012 standard. After strict inspection, product will be shipped form factory.
