Vacuum Feeder
Why choose vacuum feeder
Low pollution: Reduce the pollution of the environment and personnel on materials and improve the cleanliness
Easy to operate: It takes up little space and can complete the small space of powder transportation, making the work space beautiful and generous, and is not limited by long or short distances
No leakage: The whole conveying process is carried out in a closed system without any powder leakage.
High efficiency: Reduce labor intensity and improve work efficiency
Applicable industry
Medicine, Food, Chemicals, Metallurgy, Building materials and other industries.
Product advantage
Reduce dust pollution Reduce dust environmental pollution and improve the working environment
Improve cleanliness Reduce environmental and personnel pollution of materials
Improve work efficiency Reduce labor intensity
No leakage of sealed powderThe whole conveying process is carried out in a closed system
Applicable industry
medicine, food, chemical industry, metallurgy, building materials and other industries
Applicable materials
Various powder materials
Feed additives-antimicrobial peptides
Technical parameter
| Model | Power（kW） | Conveying capacity（kg/h） |
| ZKS-1 | 1.5 | 400 |
| ZKS-2 | 2.2 | 600 |
| ZKS-3 | 3 | 1200 |
| ZKS-4 | 5.5 | 2500 |
| ZKS-6 | 5.5 | 3200 |
| ZKS-7 | 7.5 | 6000 |
| ZKS-10-6 | 7.5 | 6000(Within 10 meters) |
| ZKS-20-5 | 11 | 5000（Within 20 meters） |
Note: The conveying capacity is measured when the conveying pipe is 4 meters long and the conveyed material is flour. The longer the conveying pipe, the conveying capacity will decrease, and the conveying capacity is also closely related to the characteristics of the material.
Working principle
The ZKS vacuum feeder uses a vacuum pump to evacuate air, so that the inlet of the suction nozzle and the entire system are in a certain vacuum state. The powder and granular materials are sucked into the feed nozzle along with the outside air, forming a material airflow, passes through the suction pipe and reaches the hopper, where the gas and material are separated. The separated material enters the material receiving equipment. Conveying and discharging materials are completed by continuously opening and closing the pneumatic three-way valve, and the opening and closing of the pneumatic three-way valve is controlled by the control center. The ZKS vacuum feeder is equipped with a compressed air backflush device. Each time the material is discharged, the compressed air pulses backflush the filter to knock down the powder adsorbed on the filter surface so that the suction material can operate normally.
